Product Model: GZ-155BLED
Product Features
- Suitable for tall structures between 90 m and 150 m in height
- High-power LED light source with long lifespan and low energy consumption
- Built-in synchronization, no additional control box required
- Synchronized flashing with just a single power cable
- Built-in light-sensing control, automatically adapts to day/night conditions
- Built for long-term outdoor installation
Applications
- High-rise buildings
- Tall chimneys
- Bridge towers
- Power transmission towers
- Communication towers
- Other medium to high-altitude aviation warning projects
Technical Specifications
| Parameter | Details |
|---|---|
| Product Name | Type B Medium-Intensity Aviation Obstruction Light |
| Product Model | GZ-155BLED |
| Light Source | LED |
| Input Voltage | AC 220V ± 20% |
| Average Power | ≤ 20W |
| Flash Rate | 20–60 flashes/min |
| Effective Intensity (Night) | 2000 cd ± 25% |
| Beam Angle | 360° |
| Light Color | Red |
| Protection Rating | IP65 |
| Operating Temperature | -40°C to +55°C |
| Humidity Range | 0 to 95% |
| Wind Resistance | ≥ 80 m/s |
| Dimensions | 230 × 230 × 400 mm |
| Net Weight | 4 kg |
| Installation Method | Vertical outdoor mounting; wall-mounted with bracket also available |
| Customization | Non-standard customization available |
| Warranty | 2 years |
| Lead Time | 3–7 days |
Installation This product is typically installed using vertical outdoor mounting. Wall-mounted installation with a bracket is also available depending on on-site project requirements. Indoor installation can be customized upon request.
Customization Non-standard customization is supported. Installation methods and selected configurations can be adjusted based on project requirements.
Lead Time & After-Sales
- Lead Time: 3–7 days
- Warranty: 2 years
- After-Sales Service: Product selection assistance, installation guidance, and technical support
Contact Us For detailed specifications, selection solutions, or quotations on the GZ-155BLED, please feel free to contact us.
